• FONE540

  • Wireless Bluetooth / USB Wired for PC
  • Full duplex microphone array speakerphone
  • Two omnidirectional microphones support 360° pickup
  • Full duplex echo cancellation
  • Advanced noise suppression
  • Powerful wideband voice processing
  • Speaker volume: 6W, adjustable to 90 dB SPL at 0.5 m
  • 3.5 mm line-in (aux) cable connects BYOD smartphones or PCs to use as speakerphones
  • Touch controls for volume down/up, mute, phone input, call, and hang up
  • Can bridge phone-in and USB into one call

• Connectivity

  • 12V power adapter
  • Micro USB connector
  • LAN for IP remote access
  • Expansion port (daisy-chain speakerphone or microphone)
  • 3.5 mm phone-in jack
  • 3.5 mm line out

• USB

  • Micro USB 2.0
  • USB Audio Class (UAC) 1.0

• Control

  • UAC, plug and play
  • WebUI: browser IP access via Chrome™ browser (Internet Explorer not supported)
  • PTZApp

• Security

  • Kensington slot

• System Requirements

  • Windows® 7/10 or later
  • Mac OS X v10.13 or later
  • Google Chromebook™ version 76.0.3809.102 or later
  • Android™ 6 or later

• Hardware Specifications

  • Processor: 3.2 GHz Intel® Core™ i5-4460 or later
  • 4 GB RAM
  • USB port

• Power Supply

  • AC 100V to 240V, 50/60 Hz
  • Consumption: 12V, 5A

• Free Applications for Meeting Collaboration (for Windows® and Mac Devices)

  PTZApp

  • Upgrade firmware automatically or manually
  • Diagnose operating status

• Environmental Data

  • Operation temperature: 0°C to 40°C
  • Operation humidity: 20% to 80%
  • Storage temperature: -20°C to 60°C
  • Storage humidity: 20% to 80%

• Dimensions

  • Package dimensions: 259 x 259 x 171 mm
  • Package weight: 1.93kg
  • Speakerphone: 220 x 181.5 x 49.5 mm/0.85 kg

• Package Contents

  • Speakerphone unit
  • Power adapter
  • Micro USB 2.0 to Type-A cable (16 ft/5 m)
  • 3.5 mm aux cable (3 ft/0.9 m)
  • Warranty card
  • Quick Start Guide

• Optional Accessories

  • Expansion speakerphone (10 m cable included), daisy-chain up to three speakerphones
  • Two expansion microphones (two 5 m cables included), daisy-chain up to four microphones

• Warranty*

  • Camera/Speakerphone: 3+2 years
  • Accessories: 1 year

  *Please register online to receive a free 2-year warranty extension. For detailed warranty information, please contact an AVer representative.

• Compatible Applications

  • Zoom, Microsoft® Teams, Skype for Business, Skype, Google Hangouts meet, Intel® Unite™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting®, TrueConf, Adobe® Connect™, Cisco Webex®, Fuze, GoToMeeting™, Microsoft® Lync™, Vidyo, vMix, WebRTC, Wirecast, XSplit

* Specifications may vary depending on countries and are subject to change without notice.
