• Camera

  • 1/2.5" and 8.51MP of CMOS
  • 4K optical lens, 120° FOV, up to 5X zoom via ePTZ*
  • Sony 4K sensor: ultra-crystal-clear image in any lighting
  • Frame rates: (16:9) 4K, 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps
  • Intelligent fill light: automatically adjusts lighting levels to make you look energetic in a dim environment**
  • SmartFrame: automatically adjusts FOV to track and fit all participants onscreen
  • Innovative Preset Framing: Follows the presenter through preset areas
  • True WDR up to 120db: 3D noise-reduction and superb backlight compensation optimize lighting in high- contrast conditions
  • Mirror, flip, AE, white balance: auto/manual override via PTZApp 2
  • Minimum focus distance: 60 cm
  • People-counting API: enterprises and third-party software providers can obtain people-counting data for better understanding of meeting-space usage
  • 10 camera presets (through remote control and IP web page)
  • Standard tripod screw holes

  *Please use PTZApp 2 to set up 5X zoom.
  **For best lighting results, sit within 1 meter away from the camera

• Microphone

  • 2 microphones
  • Frequency response: 100–12K Hz
  • Sensitivity: -37 dB

• Connectivity

  • USB type-C 3.1 connector, backward compatible with USB 2.0
  • DC jack for power adapter (for USB 2.0 connection while using fill-light function)

• Video Format

  • YUV, YUY2, MJPEG

• USB

  • 3.1 Gen 1, backward compatible with USB 2.0
  • UVC 1.1 (USB video), UAC 1.0 (USB audio), UVC1.5*
  *UVC1.5 requires an additional firmware upgrade. Please contact technical support for more details.

• Control

  • IR remote control
  • UVC/UVA plug-and-play
  • PTZApp 2

• Security and Mount

  • Built-in TV clip
  • Kensington slot
  • 1/4" tripod mounting screw

• System Requirements

  • Windows® 7/10/11
  • MacOS 10.14 or later
  • Google Chromebox 3 version 94.0.4606.114 or later

• Hardware Specs

  • 3.2 GHz Intel® Core™ i5-4460 processor
  • 4 GB RAM or more
  • USB 3.1 port, backward compatible with USB 2.0

• Power Supply

  • AC 100V–240V, 50/60 Hz
  • 5V/2A

• Free Applications for Meeting Collaboration
  (For Windows® and Mac® computers)

  EZManager 2: Camera Central Management Software

  • Remotely group FW/SW upgrades, control the camera, and manage settings

  PTZApp 2: Camera Settings Software

  • View live video, people-counting numbers, and meeting-interval information
  • Enable Skype for Business far-end control
  • Upgrade firmware automatically or manually
  • Control the camera
  • Set parameters and adjust the camera image
  • Diagnose operating status

  EZLive: Broadcasting Software

  • Enjoy multi-camera real-time streaming, annotating, image capturing, and video recording

• Environmental Data

  • Operation temperature: 0 to 40°C
  • Operation humidity: 20% to 80%
  • Storage temperature: -20 to 60°C
  • Storage humidity: 20% to 80%

• Dimensions

  • Package dimensions: 217(L)*155(W)*118(H) mm
  • Package weight: 0.729 kg
  • Camera: 160 (L) x 37 (H) x 60 (D) mm/ 0.282kg
  • Remote control: 149.72 x 42.3 x 19.29 mm/50g (optional item)

• Package Contents

  • CAM130 unit
  • Power adapter (10 ft/3 m)
  • USB 3.1 type-C to type-A cable (6 ft/1.8 m)
  • QR code card

• Optional Accessories

  • Remote control (also compatible with VB130)
  • USB 2.0 type-C to type-A cable (15 ft/5 m)
  • USB 3.1 Extension Cable (10 m/20 m/30 m)

• Warranty

  • Camera: 3 years
  • Accessories: 1 year

• Compatible Applications

  • Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit

* For 4K UHD support, please check system/hardware requirements with your software application provider.
* Specifications may vary depending on countries and are subject to change without notice.
