Tính năng

Đặc tính kỹ thuật

  • Camera
    • 1/2.5" and 8.51MP of CMOS
    • 4K optical lens, 120° FOV, up to 5X zoom via ePTZ*
    • Sony 4K sensor: ultra-crystal-clear image in any lighting
    • Frame rates: (16:9) 4K, 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps
    • Intelligent fill light: automatically adjusts lighting levels to make you look energetic in a dim environment**
    • SmartFrame: automatically adjusts FOV to track and fit all participants onscreen
    • Innovative Preset Framing: Follows the presenter through preset areas
    • True WDR up to 120db: 3D noise-reduction and superb backlight compensation optimize lighting in high- contrast conditions
    • Mirror, flip, AE, white balance: auto/manual override via PTZApp 2
    • Minimum focus distance: 60 cm
    • People-counting API: enterprises and third-party software providers can obtain people-counting data for better understanding of meeting-space usage
    • 10 camera presets (through remote control and IP web page)
    • Standard tripod screw holes
    *Please use PTZApp 2 to set up 5X zoom.
    **For best lighting results, sit within 1 meter away from the camera
  • Microphone
    • 2 microphones
    • Frequency response: 100–12K Hz
    • Sensitivity: -37 dB
  • Connectivity
    • USB type-C 3.1 connector, backward compatible with USB 2.0
    • DC jack for power adapter (for USB 2.0 connection while using fill-light function)
  • Video Format
    • YUV, YUY2, MJPEG
  • USB
    • 3.1 Gen 1, backward compatible with USB 2.0
    • UVC 1.1 (USB video), UAC 1.0 (USB audio), UVC1.5*
    • *UVC1.5 requires an additional firmware upgrade. Please contact technical support for more details.
  • Control
    • IR remote control
    • UVC/UVA plug-and-play
    • PTZApp 2
  • Security and Mount
    • Built-in TV clip
    • Kensington slot
    • 1/4" tripod mounting screw
  • System Requirements
    • Windows® 7/10/11
    • MacOS 10.14 or later
    • Google Chromebox 3 version 94.0.4606.114 or later
  • Hardware Specs
    • 3.2 GHz Intel® Core™ i5-4460 processor
    • 4 GB RAM or more
    • USB 3.1 port, backward compatible with USB 2.0
  • Power Supply
    • AC 100V–240V, 50/60 Hz
    • 5V/2A
  • Free Applications for Meeting Collaboration
    (For Windows® and Mac® computers)
    EZManager 2: Camera Central Management Software
    • Remotely group FW/SW upgrades, control the camera, and manage settings
    PTZApp 2: Camera Settings Software
    • View live video, people-counting numbers, and meeting-interval information
    • Enable Skype for Business far-end control
    • Upgrade firmware automatically or manually
    • Control the camera
    • Set parameters and adjust the camera image
    • Diagnose operating status
    EZLive: Broadcasting Software
    • Enjoy multi-camera real-time streaming, annotating, image capturing, and video recording
  • Environmental Data
    • Operation temperature: 0 to 40°C
    • Operation humidity: 20% to 80%
    • Storage temperature: -20 to 60°C
    • Storage humidity: 20% to 80%
  • Dimensions
    • Package dimensions: 217(L)*155(W)*118(H) mm
    • Package weight: 0.729 kg
    • Camera: 160 (L) x 37 (H) x 60 (D) mm/ 0.282kg
    • Remote control: 149.72 x 42.3 x 19.29 mm/50g (optional item)
  • Package Contents
    • CAM130 unit
    • Power adapter (10 ft/3 m)
    • USB 3.1 type-C to type-A cable (6 ft/1.8 m)
    • QR code card
  • Optional Accessories
    • Remote control (also compatible with VB130)
    • USB 2.0 type-C to type-A cable (15 ft/5 m)
    • USB 3.1 Extension Cable (10 m/20 m/30 m)
  • Warranty
    • Camera: 3 years
    • Accessories: 1 year
  • Compatible Applications
    • Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit

* For 4K UHD support, please check system/hardware requirements with your software application provider.
* Specifications may vary depending on countries and are subject to change without notice.

URL

accessories

  • CAM130
  • PN: 04131AGOOARJ(Adapter) PN: 041399ECOAPA(EU plug) PN: 041399UGOAPD(UK plug) PN: 041399NHOAPC(AU plug) PN: 041399FAOAPB(US plug)
    Power Adapter
  • PN:064AUSBCDL
    USB 3.1 Type-C to Type-A Cable 1.8 m
  • Tripod Screw
  • QR Code Card
  • PN: 0412U360-ASJ
    Remote Control
  • PN: 064AUSB−−CC5(10m) PN: 064AUSB−−CC6(20m) PN: 064AUSB−−CDS(30m)
    USB 3.1 Extension Cable 10 m/20 m/30 m
  • PN:064AUSBCFN
    USB 2.0 Type-C to Type-A Cable 5 m
  • Wall/Ceiling mount PN: 60U8C00000AD
    Wall/Ceiling mount
  • PN: 60U3600000AB
    Tripod
