EVC170

• Package contents

  • Main system unit (codec)
  • eCam PTZ IV camera
  • EVC microphone array
  • IR remote control with batteries
  • Power supply
  • Cables
  • Warranty card
  • Quick guide

• Communications

  • H.323, SIP standards, SIP TLS
  • Call-Quality bandwidth 64Kbps ~ 8Mbps
  • RJ45 network LAN (10/100/1000)
  • Manual max. bandwidth settings (up to 12Mb Send/Receive)

• Camera

  • eCam PTZ IV camera FullHD 1080P@60fps
  • 2-megapixel CMOS sensor
  • Auto focus
  • 18X total zoom (12X optical + 1.5X digital)
  • ±130° pan; +90°/-25° tilt
  • 72° FOV (H); 43° FOV (V); 82° FOV (diagonal)
  • Connect via port 1394
  • Remote control via web
  • Support 9 positions via remote, max 100 positions

• People video resolutions (up to 60fps)

  • HD 1080p (1920 x 1080)
  • HD 720p (1280 x 720)
  • 480p (848 x 480)
  • 4CIF (704 x 576)
  • CIF (352 x 288)
  • SIF (352 x 240)
  • Rx Auto 1080P@30fps

• Content video resolutions

  HDMI-supported resolutions

  • 1080p (1920 x 1080)
  • 720p (1280 x 720)
  • D1 (720 x 480)
  • SXGA (1280 x 1024)
  • XGA (1024 x 768)
  • SVGA (800 x 600)
  • VGA (640 x 480)

  Output resolutions:

  • Up to HD1080p (1920 x 1080) up to 60fps

• Video standards

  • H.261, H.264, H.264 High Profile, H.264 SVC, H.263+, H.263

• Video features

  • 3D denoise

• Video inputs

  • Main camera eCam PTZ IV (1394 standard)
  • HDMI/VGA/DVI for presentation
  • Support wireless content sharing for presentation via software (IP UDP)

  Content sharing inputs

  • H.239 dual-video streams
  • Support wireless content sharing for presentation via software
  • IP UDP, VGA/HDMI port

• Video outputs (max 3 screens)

  • HDMI x 2
  • VGA

• Audio standards

  • G.711, G.722, G.722.1, G.728, G.722.1C, AAC-LD, G729

• Audio features

  • Automatic gain control (AGC)
  • Advanced noise reduction (NR)
  • Acoustic echo cancellation (AEC)

• Audio inputs

  • EVC microphone daisy chain up to 4 (microphone 8 pin port)
  • HDMI
  • Line-in (3.5 mm)

• Audio outputs

  • HDMI x 2
  • Line-out (3.5 mm Analog)

• Other supported standards

  • H.224, H.225, H.245, H.281, H.323 Annex Q, H.235, H.350, H.460
  • RTP, RTCP, SRTP, BFCP content sharing, HTTP, HTTPs, Telnet, DHCP, DNS

• User interface

  • Single/dual-monitor layout styles
  • User-friendly OSD
    (23 supported languages: English, Traditional Chinese, Simplified Chinese, Czech, Danish, Dutch, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Brazil, Romanian, Russian, Spanish, Swedish, Thai, Turkish, Vietnamese)
  • Display/edit site name

• Network

  • 10/100/1000Mbps
  • NAT/firewall traversal (H.460)
  • High Efficiency Lost Packet Recovery (HELPeR™)
  • API support via Telnet
  • Packet Loss Recovery (PLR)
  • Wake-on-LAN (WOL) support
  • IPv4 and IPv6 support
  • Network test
  • Quality of service (QoS)
  • VLAN (802.1Q / 802.1P)
  • EAP 802.1x

• Security

  • AES (Advanced Encryption Standard) function (128-bit) and H.235
  • Password protection for system settings
  • Password protection for remote system management

• Web management tool

  • Remote management
  • Live monitoring
  • Firmware update
  • Phonebook download/upload/edit
  • Restore system settings
  • Export call history
  • HTTP and HTTPs

• Value-added features

  • Meeting recording
    • In-meeting and offline recording
    • Save directly to USB flash drive or NAS
    • Supports screen re-layout during playback
    • Playback and file conversion via VCPlayer software (.MOV and .MP4 format)
  • EZMeetup / EZMeetup Plus software/App
    • 30-day for free trial
    • Connect with H.264 and H.264 HP video codecs
    • Receive resolution up to full HD 1080p at 30fps
    • Transmit resolution up to full HD 1080p at 30fps
    • Support content sharing, capturing and recording
    • Support log-in, one - one call (max 5 pairs at the same time with main call)
  • Dual-monitor support output (video and content sharing)
  • Video layout: Full screen, Picture in Picture, Side by Side
  • Speed dialing via hot keys (10 sets)
  • Camera presets (9positions via remote, max 100 positions)
  • Firmware updates via USB flash drive
  • 02 USB ports
  • Screensaver and auto power-off mode
  • Network Time Protocol (NTP)
  • SnapShot
  • Supports SIP voice calls
  • Supports mixed protocol H.323, SIP, WebRTC at the same call
  • iSCSI storage device settings
  • Built-in meeting server
  • Supports AVer Register Server (ARS)
  • Far-end Camera Control
  • Meeting ID method

• Power supply

  • AC 100V ~240V, 50/60 Hz, 200W
  • Consumption: EIAJ 12V, 5A

• Environmental data

  • Operation temperature: 0 ~ 40°C
  • Operation humidity: 20 ~ 80%
  • Storage temperature: -20 ~ 60°C
  • Storage humidity: 20 ~ 80%

• Physical characteristics

  • Package dimensions: 376 x 300 x 243 mm
  • Package weight: 6.99kg (14.31lbs)
  • Main system (codec): 320 x 262.7 x 37.2 mm
  • eCam PTZ IV: 180 x 144 x 184 mm
  • EVC microphone array: 131.9 x 118.6 x 25.5 mm

• Optional accessories

  • Additional microphone
  • Camera mount
  • USB-to-RS232 converter

• Warranty**

  • Camera/Codec/Microphone: 3 year
  • Accessories: 1 year

*Specifications may vary depending on countries and are subject to change without notice.
**G.722.1/G.722.1C, licensed from Polycom^®
